Seasonic FOCUS SGX SFX GOLD 650W, modular

Podrobný popis

FOCUS SGX The long-awaited new line of Seasonic’s FOCUS SGX is versatile in its application, and powerful with a small footprint. The FOCUS SGX is shipped with an SFX to ATX adapter bracket in the box, which allows the power supply to be mounted not only in the SFX form factor chassis, but also a standard ATX chassis should the user prefers to reserve more space for airflow inside the PC case. The Seasonic hybrid fan control is always enabled to optimize the cooling according to necessity. Specifications 650 W 500 W 450 W Technical Specifications 80PLUS® Gold Cybenetics Efficiency Level Gold Cybenetics Noise Level Standard+ Form Factor SFX Dimensions 125 × 125 × 63.5 mm Fan Information Fan Size 120 mm Fan Control Premium Hybrid Fan Control Fan Bearing Fluid Dynamic Bearing Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH Cable Information Modularity Fully Modular Cable type Black Flat Cables Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C linearly) MTBF @ 25 °C, excl. fan 100,000 hours AC Input Full Range Protection OPP, OVP, UVP, OCP, OTP, SCP Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH Warranty 10 Years Power Output AC Input 100 V - 240 V 9 - 4.5 A 50 Hz - 60 Hz DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB Maximum Power 20 A 20 A 54 A 0.3 A 3 A 100 W 648 W 3.6 W 15 W Total continuous power 650 W
